Auger Filling Machine - AP100J

Auger Filling Machine - AP100J
Auger Filling Machine - AP100J
Product Code : AP100J
Product Description

Auger Filler - Jumbo for Large Pack sizes

Auger fillers are versatile filling machines for free-flowing as well as non-free flowing powders and thick pastes. Machine can handle wide range of products and pack sizes starting from 250gms to 5Kg. Machine operates on the principle of Positive displacement of screw operating under constant head of powders. Precisely designed Auger screw displaces powder through funnel into pouches /container held under the funnel. Auger filler model AP-100J is designed specifically for Larger packsizes. Higher hopper capacity ensures that the large quantity of powder is held in the hopper which reduces the material handing efforrts. contact powder level maintained in the hopper also provides the higher accuracy.

Integrated screw feeder and storage tank can be provided to feed the powder directly in the machine hopper.

Suitable for

- Ground spices,Atta, Talcum Powder ,Coffee, Milk powder, Chemicals, Pesticides, Grease, Herbal Powders,Flour

Salient Features

- Time testred, Quality product.
- Capacity to handle wide range of products and pack sizes.
- Contact parts made from S.S. 304 (S.S. 316 contact parts on request)
- Easy changeover of product and pack sizes.
- Sturdy, simple construction assists maintenance and cleanliness.
- Automatic in-feed and off-take conveyor is available
- Bottom up filling is available

Technical Specifications

 Item  Parameters  Specifications
  Operational
 Specifications
 Capacity  From 250gms to 5000gms  powder
 Control   Solid state electronic controller
 Operation  mode   Auto and manual mode  with adjustable delay time between the fills
 Filling speed   Upto  15 pouches  per minute of 250gms packsize, depending upon bulk density, product flowability and efficiency of operator.
 Auger & funnel  Machine will be provided with one set of auger and funnel for filling one  range of packsize.
 Filling accuracy  + 2% at constant powder level in the machine hopper and  consistancy of bulk density
 Powder feeding   To be arranged by you.
 Control panel  Moc  SS304  with MS component plate
 Controller  Solid state electronic controller with photoelectric sensor.
 Filling  mode   Volumetric filling mode
 Drive  Motor   2 hp motor with variable speed drive
 Clutch/Brake  Electromagnetic clutch/brake unit for filling control
 Stirrer   Through heavy metallic  helical gearing.
 Stirrer elements  Stirrer elements are heavier for large quantity of powder
 Physical
 specifications
 Machine hopper  80 litres
 MOC  All parts coming in direct contact of the product made from s.s. 304. All other parts made from ms/ci ( for gmp models all parts are made from
 s.s.304 or covered with ss304 sheets. )
  Overall
 dimensions
 Main machine  950mm x 1000mm x 1250mm
 Supporting frame  750mm x 900mm x 900mm
 Net weight   275kgs approx
 Mobility  Main machine with frame provided with castor wheels.
