Continuous Sealer

Continuous Sealer
Continuous Sealer
Product Code : CBS 30G
Product Description

Continuous Band Sealer - CBS30GMP

Semi-automatic sealing machines are ideal for sealing Virgin and laminated pouches. Presettable Digital temperature controller is used to monitor the temperature for different types of pouch material. Sealing is achieved by heat conducted through Ptfe coated gripper belts for continuous Band sealers. The hot Gripper belts carry the pouch and cause localize melting of pouch material. and subsequent sealing by metallic and rubber pressure roller. The pouch carrying conveyor and gripper belts are driven by common drive resulting in synchronous movements of pouches.

Suitable for

- Virgin/Laminated Heat sealable pouches. Ideal for salt, Detergent and  where Industries where different pack-sizes are
  required to be sealed.

Salient Features :

- GMP model suitable for salt/detergent and Heavy industry.
Ideal for sealing of Virgin and Laminated pouches.
Time Proportional Digital Temperature Controller
- Single drive for Sealing head and in built pouch conveyor for better synchronization.
Easily adjustable Pouch length.

Technical Specifications

 Parameters  Specifications
 Material sealed  Virgin / laminated heat sealable pre formed pouches.
 Bag sizes handled  Adjustable from 100 mm to 400 mm height
 Seal width  6 mm
 Model of heat transfer  Through endless PTFE coated belts.
 Power  Motor: 0.5 h.p., 3 phase 440v ac 1400rpm, 50hz
 Heaters  250w x 2nos
 Pouch conveyor  Built in pouch conveyor of 195mm width and 1500mm long.
 Operating speed  Upto 9 meters per minute belt speed the sealing speed depends
 upon the bag width and efficiency of operator.
 M.O.C.  MS/CI construction duly powder coated/painted. (For gmp
 models, all parts are made from / covered with ss 304 sheets.)
 Mobility  Provided with castor wheels
 Overall dimensions  1500 mm (I) x 550 mm (w) x 1350 mm (h)
 Packing dimensions  1200 mm (I) x 700 mm (w) x 1500 mm (h)
 Net weight  170 kgs. Approx.
 Gross weight  350 kgs approx.
