Item
|
Parameters
|
Specification
|
|
Operational Specifications
|
Capacity
|
From 10ml to 1000ml with change parts
|
|
|
Products
|
Easily flowable homogeneous liquids
|
|
|
Control
|
Volumetric piston with adjustable stroke
|
|
|
Operation mode
|
Cyclic with suction and discharge.
|
|
|
Bottle placement
|
Manual
|
|
|
Bottle stoppers.
|
Adjustable bottle stoppers provided
|
|
|
Spillage duct
|
Spillage duct with tray provided to collect any spillage.
|
|
|
Filling speed
|
Upto 15 bottles per minute, depending upon nature of the liquid, packsize. And efficiency of operator.
|
|
|
Syringes
|
Machine is not provided with syringes. Syringes for the required packsize can be supplied to meet your requirement.
|
|
|
Filling accuracy
|
+ 1% for uniform liquid properties
|
|
Drive
|
Motor
|
0.75 hp motor with optional variable speed drive
|
|
|
Gear box
|
Specially designed gear box with one piece integral shaft without any joints to drive the eccentric blocks.
|
|
|
Eccentric block
|
One piece s.s. 304 eccentric block for volume adjustment with heavy construction.
|
|
Physical specifications
|
Moc
|
All parts coming in direct contact of the product made from s.s. 304. All other parts made from ms/ci (for gmp models all parts are made from s.s. 304 or covered with ss304 sheets.)
|
|
|
Guards
|
Body covering, guards etc are made from ss 304
|
|
Diving nozzle option (If-2d)
For foaming liquids.
|
Diving nozzle operation
|
Pneumatic
|
|
|
Nozzle holder
|
Aluminum
|
|
|
Pneumatics
|
Camozzi make
|
|
|
Compressed air
|
To be arranged by you.
|
|
|
Stroke
|
9 inches diving stroke max.
|
|
|
Control
|
With inductive proximity switch.
|
|
Overall dimensions
|
Main machine
|
750mm x 700mm x 700mm
|
|
|
Supporting frame
|
650mm x 400mm x 700mm
|
|
|
Net weight
|
225 kgs approx without syringes.
|
|
|
Mounting.
|
Machine with frame provided with polyamide legs.
|
