Liquid Filler Machine
The Macromedia Flash help system contains a great deal of information and resources that describes the full range of Flash authoring capabilities and the Action Script language. Many online resources are also available to help your learn Flash. This document is intended to help you navigate these resources and find the information that is most helpful to you in realizing your goals with Flash.
For specific information about using the Flash documentation, see the following sections :
|
Item
|
Parameters
|
Specifications
|
|
OPERATIONAL
SPECIFICATIONS
|
CAPACITY
|
FROM 100 GMS TO 1000 ml with change parts
|
|
PRODUCTS
|
Easily flowable homogeneous liquids
|
|
CONTROL
|
Volumetric piston with adjustable stroke.
|
|
OPERATION MODE
|
Cyclic with suction and dicharge.
|
|
BOTTLE PLACEMENT
|
Manual
|
|
BOTTLE STOPPERS
|
Adjustable bottle stoppers provided
|
|
SPILLAGE DUCT
|
Spillage duct with tray provided to collect any spillage.
|
|
FILLING SPEED
|
Upto 15 bottles per minute, depending upon nature of the liquid, packsize and effciency of operator.
|
|
SYRINGES
|
Machine is not provided with syringes. Syringes for the required packsize can be supplied to meet your requirement.
|
|
FILLING ACCURACY
|
+ 1% for uniform liquid properties
|
|
DRIVE
|
MOTOR
|
0.75 hp motor with optional variable speed drive.
|
|
Gear box
|
Specially designed gear box with one piece intgral shaft without any joints to drive the eccentric blocks.
|
|
Eccentric block
|
One piece s.s304 eccentric block for volume adjustable with heavy construction.
|
|
PHYSICAL SPECIFICATIONS
|
MOC
|
All parts coming in direct contact of the product made form s.s 304. All other parts made from ms / ci (for gmp models all parts are made from s.s 304 or covered with ss 304 sheets)
|
|
GUARDS
|
Body covering, guards etc are made from ss 304.
|
|
DIVING NOZZLE OPTION (IF-2d) FOR FOAMING LIQUIDS
|
DIVING NOZZLE OPERATION
|
Pneumatic
|
|
NOZZLE HOLDER
|
Aluminum
|
|
PNEUMATICS
|
Camozzi make
|
|
COMPRESSED AIR
|
To be arranged by you
|
|
STROKE
|
9 inches diving stroke max.
|
|
CONTROL
|
With inductive proximity switch
|
|
OVERALL DIMENISIONS
|
MAIN MACHINE
|
750 MM X 700 MM X 600 MM
|
|
SUPPORTING FRAME
|
650 MM X 400 MM X 700 MM
|
|
NET WEIGHT
|
225 KGS Approx without syringes
|
|
|
MOUNTING
|
Machine with frame provided with polyamide legs.
|
|
