Item
|
Parameters
|
Specifications
|
|
OPERATIONAL
SPECIFICATIONS
|
CAPACITY
|
FROM 2 GMS TO 35 GMS POWDER
|
|
CONTROL
|
SOLID STATE ELECTRONIC CONTROLLER
|
|
OPERATION MODE
|
AUTO AND MANUAL MODE WITH ADJUSTABLE DELAY TIME BETWEEN THE FILLS
|
|
FILLING SPEED
|
UPTO 25 DISCHARGES PER MINUTE DEPENDING UPON BULK DENSITY, PRODUCT FLOWABILITY BOTTLE MOUTH SIZE AND EFFICIENCY OF OPERATOR.
|
|
AUGER & FUNNEL
|
MACHINE WILL BE PROVIDED WITH ONE SET OF AUGER AND FUNNEL FOR FILLING ONE RANGE OF PAKSIZES.
|
|
FILLING ACCURACY
|
+ 2% AT CONSTANT POWDER LEVEL IN THE MACHINE HOPPER AND CONSISTANCY OF BULK DENSITY
|
|
POWDER FEEDING
|
FROM BULK HOPPER WITH SCREW FEEDER CONTROLLED BY A LEVEL CONTROLLER.
|
|
CONTROL PANEL
|
MOC
|
SS304
|
|
CONTROLLER
|
SOLID STATE ELECTRONIC CONTROLLERS WITH PHOTOELECTRIC SENSOR FOR FILLING.
|
|
|
SOLID STATE ELECTRONIC LEVEL CONTROLLER FOR CONTROLLED POWDER FEEDING INTO THE DOZER HOPPER.
|
|
FILLING MODE
|
VOLUMETRIC FILLING MODE
|
|
DRIVE
|
MOTOR
|
0.5 HP 440V A.C. 1400 RPM 50 HZ MOTOR
|
|
FEEDER DRIVE
|
20KG CM AC SYNCHRONOUS MOTOR
|
|
CLUTCH / BRAKE UNIT
|
ELECTROMAGNETIC CLUTCH / BRAKE UNIT FOR FILLING CONTROL
|
|
STIRRER
|
THROUGH HELICAL GEARING.
|
|
PHYSICAL SPECIFICATIONS
|
MACHINE HOPPER
|
7 LITRES.
|
|
DOZER HOPPER
|
1 LITRE WITH ACRYLIC CYLINDER FOR VISIBILITY.
|
|
FRAME
|
S.S. 304 SQUARE TUBE FRAME WITH TOP CLADING TABLE
|
|
MOC
|
ALL PARTS COMING IN DIRECT CONTACT OF THE PRODUCT MADE FROM S.S. 304. ALL OTHER PARTS MADE FROM MS/CI ( FOR GMP MODELS ALL PARTS ARE MADE FROM S.S.304 OR COVERED WITH SS304 SHEETS. )
|
|
OVERALL DIMENSIONS
|
MAIN MACHINE
|
900 MM X 675 MM X 1800 MM
|
|
NET WEIGHT
|
190 KGS APPROX.
|
|
|
MOBILITY
|
MAIN MACHINE WITH FRAME PROVIDED WITH CASTOR WHEELS.
|
