Item
|
Parameters
|
Specifications
|
|
OPERATIONAL
SPECIFICATIONS
|
CAPACITY
|
UPTO 1000 ml PASTE WITH CHANGE PARTS
|
|
PRODUCTS
|
THICK FLOWABLE HOMOGENEOUS PASTE
|
|
CONTROL
|
LOAD CELL BASED MICRPROCESSOR CONTROLS.
|
|
OPERATION MODE
|
COARSE AND FINE MODE OF PRODUCT DISCHARGE.
|
|
BOTTLE PLACEMENT
|
MANUAL
|
|
FILLING SPEED
|
UPTO 15 BOTTLES PER MIUNUTE, DEPENDING UPON NATURE OF THE LIQUID, PACKSIZE AND EFFICIENCY OF OPERATOR.
|
|
FILLING HEAD
|
TWO FILLING HEADS WITH TWO LOAD CELL PLATFORMS.
|
|
FILLING ACCURACY
|
+ 1% FOR UNIFORM PAST PROPERTIES
|
|
VALVE
|
PNEUMATICALLY OPERATED VLVE WITH FINE AND COARSE FILLING ARRANGEMENT.
|
|
DRIVE
|
MOTOR
|
1 HP MOTOR WITH VARIABLE SPEED DRIVE
|
|
STIRRER DRIVE
|
THROUGH HELICAL GEARING.
|
|
PHYSICAL SPECIFICATIONS
|
HOPPER
|
50 LITRES. WITH OPTIONAL JACKET WITH HEATER AND TEMPERATURE CONTROLS.
|
|
MOC
|
ALL PARTS COMING IN DIRECT CONTACT OF THE PRODUCT MADE FROM S.S. 304. ALL OTHER PARTS MADE M.S./CI (FOR GMP MODELS ALL PARTS ARE MADE FROM S.S.304 OR COVERED WITH ss304 SHEETS)
|
|
OVERALL DIMENSIONS
|
MAIN MACHINE
|
1000 MM X 700 MM X 1200 MM
|
|
NET WEIGHT
|
325 KGS APPROX
|
|
MOUNTING
|
SQUARE TUBE FRAME PROVIDED WITH CASTOR WHEELS.
|
