Item
|
Parameters
|
Specifications
|
|
OPERATIONAL
SPECIFICATIONS
|
CAPACITY
|
SILO CAPACITY OF 1000 LITRES.
|
|
CONTROL
|
CAPACITANCE TYPE LEVEL CONTROLLER.
|
|
OPERATION MODE
|
AUTO AND MANUAL MODES
|
|
FEEDER SCREW
|
VERTICALLY MOUNTED S.S.304 FEEDER SCREW OF NOMINAL DIAMETER OF ABOUT 125MM OPERATING ON RECEIPT OF SIGNAL FROM LEVEL CONTROLLER.
|
|
POWDER FEEDING
|
TO BE ARRANGED BY YOU. (MOUNTING CAN BE ADJUSTED SUCH THAT IT CAN RECEIVE POWDER FROM THE SIFTER OUTLET.
|
|
CONTROL PANEL
|
MOC
|
SS304 / OR COMPOSIT WITH THE AUGER FILLER CONTROL PANEL
|
|
CONTROLLER
|
SOLID STATE LEVEL CONTROLLER WITH PROBE
|
|
DRIVE
|
MOTOR
|
1.5 HP MOTOR WITH SUITABLE GEARBOX.
|
|
STIRRER
|
INTEGRAL WITH SCREW DRIVE.
|
|
PHYSICAL SPECIFICAIONS
|
SILO CAPACITY
|
1000 LITRES.
|
|
FRAME
|
SQUARE TUBE FRAME FOR MOUTING OF SILO AND THE FEEDER DRIVE DULY POWDER COATED.
|
|
MOUNTING
|
THE SILO AND FEEDER WILL BE MOUNTED ON MAZENNINE FLOOR AT MINIMUM 2800 MM ABOVE GROUND. AN OPENING OF ABOUT 1400 MM DIA. TO BE PROVIDED FOR SUSPENDING THE SILO CONE FROM THE MAZENNINE FLOOR.
|
|
|
M.O.C.
|
SILO, SCREW FEEDER STIRRER ETC. MADE FROM S.S.304. FRAME DRIVE MOUNTING ETC. WILL BE MADE FROM M.S. DULY POWDER COATED.
|
|
DIMENISIONS
|
OVERALL DIMENSIONS
|
1500 MM X 1500 MM X 1500 MM ABOVE MAZENNINE FLOOR.
|
|
SILO INLET
|
900 MM ABOVE MAZENNINE FLOOR.
|
|
SCREW FEEDER OUTLET
|
1000 MM BELOW MAZENNINE FLOOR
|
|
NET WEIGHT
|
500 KGS APPROX
|
