Ribbon Blender

Ribbon Blender
Ribbon Blender
Product Code : RB 150
Product Description

Fostered with rich industry experience and knowledge, we are able to manufacture, export and supply an excellent quality range of Ribbon Blender. This blender is used for mixing of dry granules & powders homogeneously. The offered Ribbon Blender is manufactured in our state-of-the-art manufacturing unit in compliance with international quality standards using the best quality components and high-end technology. Our clients can avail this blender from us in various technical specifications at industry leading price.

Features:

  • Sturdy construction

  • Durability

  • Superior performance

  • Long life

Other information:

For Bro offers  high quality Ribbon Blender an efficient and versatile blending machine for mixing of dry granules & powders homogeneously. Approximate two third of the volume of the container of Ribbon Blender is filled to ensure proper mixing.The Ribbon Blender gives best result for mixing of dry powder & granules due to the design and shape of the mixing ribbon and product container.

Material is charge from the top side opening known as port. One discharge valve provided at the bottom side at center of the container.The discharge height could be adjust as per the requirement, so that material gets discharge in the other container/Sifter/Vibro sifter directly. This reduces the material handling time of discharge and also reduces efforts in moving material to one process point to other.

Specially designed container ensures that the material is mixed correctly with out any material clogging in the corners.

Suitable for

  • Pharmaceutical, Food, Chemical and cosmetic products

Salient Features:

  • Up to 1000 liters with Microprocessor Controlled operation

  • GMP model with sifter & spray Nozzle Available.

  • Feeding Arrangement & Automatic discharge system available

  • SS304/SS316 MOC available as per the requirements

  • Dual direction operations ensures homogeneous mixing

  • Auto cut-off for attention free operations

  • Microprocessor based controls for ease of operations.

  • Modular design to facilitate maintenance and cleaning

  • Special port can be provided for adding material/colour etc at pre-defined time without stopping the machine.

Technical Specifications:

Item Parameters Specifications
  Main body  MOC  M. S. Structural for the main frame and drive support frame
 Blender trough  Stainless steel: grade 304.
 Capacity: 125 litres.
 Two heavy plates made from ms. Covered with s.s. 304 sheets will support
 the 'u' shaped trough.
 Outlet: through macon valve.
 Blender shaft &
 ribbon.
 Two ribbons integral with the main shaft running in opposite direction run with minimum clearance from the u shaped trough. Shaft and ribbon made from s.s 304 are supported on bearings in plummer blocks. PTFE gland packing cover is provided on the trough plates.
 Blender cover.  SS. 304 over with proximity switches for open cover.
  Control panel  MOC   Stainless steel grade 304
 Timer control  Timer control for setting of blending time up to 999 minutes.
 Buzzer  Buzzer is provided for indication of cycle completion. The buzzer remains on until reset by the operator.
 Motor  3 h.p. 3 phase, 440v a.c. 50 hz. 1400 Rpm
        Drive  Gear box  Worm reduction gearbox
 Coupling  Bush pin type coupling.
 MOC  M.S. Structural for the main frame and drive support frames (s.s 304 square tubes and structural made from s.s. 304 or m.s. / ci. Covered with s.s. 304 sheets
       Physical
 Specifications
 Mobility  Fixed the masonary work
 Overall Dimensions  1800 mm x 850 mm x 1450 mm
