Sachet Packer - Grannules and Pulses

Sachet Packer - Grannules and Pulses
Sachet Packer - Grannules and Pulses
Product Code : SP-100V
Product Description

Sachet Packer  Machine - Granules, Pulses and Detergent

Sachet packing machines offer packing solutions for powders, granular products, liquids and pastes mainly in small size unit packs. Varity of dozing heads available makes these machines capable of handling various products with different physical properties. Machines packs product in to 3 or 4 side sealed pillow pouches formed from printed laminate roll . Photoelectric registration helps in precise print positioning on the pouch is provided.

 Suitable for

- Wholse Spices, Granular Chemicals, Sauf/Dhanadal , Mukhwas, pulses, Grains, Detergent, Salt, Pepper etc,

Other Dozing Units

- Auger Filler: With Photoelectric sensor controls for dozing of non-free flowing/fluffy powders
- Volumetric Cup Filler: With/Without volume adjustment for free flowing powders
- Liquid Dozer: Piston pump with micro adjustment of volume
- Paste Filler: For dozing of thick viscous liquids with pump and pressure screw if required

Salient Features:

- Easy changeover of pack size and output control.
- GMP and Standard models.
- Robust construction with user friendly controls.
- Photoelectric registration for precise print positioning.
- Contact parts made from S.S.304 (S.S.316 contact parts on request)


 Technical Specifcations

Item Parameters Specifications
Operational specifcations Capacity From  10gm 50gms free flow grannules
Control  Electromechanical  with photoelectric sensor.
Operation  mode  Automatic
Packing speed  Upto  30 pouches per minute with single tracks depending upon the product density and packsize.
Pouch formation With liner former  with max size upto 220mm width of laminate.
Pouch type 3/ 4 side sealed  pouch.
Max pouch size 100mm x 150mm max.
Vertical seals Roll  pulling and vertical seales with die rollers through epicyclic gear train.
Horizontal seals With  rotary cross seal rollers with eccentric  for matching of linear speed of pouch movement.
Heaters Cartridge heaters 250w x 4nos.
Dozer Volumetric cup filler for grannular products  with height adjustmen and provided with components suitable for one  paksizes.
Filling accuracy + 2% at constant powder level in the machine hopper and  consistancy of bulk density
Product feeding  To be arranged by  you  (can be supplied optionally)
Machine hopper 10 litres.
Control panel Moc Inbuilt with the machine. M.s.body
Controller Solid state  electronic controller with photoelectric sensor for  print mark registration.
Temperature controllers Digital time proportional  temperature controllers with j type thermocouples.
Drive Motors  0. 5 h.p. Single phase . For main machine (variable speed drive optional)
Gear box Worm reduction gear box
Physical specificaions Moc  All parts coming in direct contact of the product made from s.s. 304. All other parts made from MS/CI ( for GMP models all parts are made from s.s.304 / covered with ss304 sheets/ ENP coated. )
Main machine 900mm x1000mm x 1800mm
Net weight  550kgs approx.
Mobility Provided with castor wheels..
