Item
|
Parameters
|
Specifications
|
|
OPERATIONAL
SPECIFICATIONS
|
CAPACITY
|
FROM 10 ML 100 ML WITH CHANGE PARTS
|
|
PRODUCTS
|
EASILY FLOWABLE HOMOGNEOUS LIQUIDS.
|
|
CONTROL
|
VOLUMETRIC PISTON WITH ADJUSTABLE STROKE.
|
|
OPERATION MODE
|
CYCLIC WITH SUCTIONAND DISCHARGE.
|
|
BOTTLE PLACEMENT
|
MANUAL
|
|
BOTTLE STOPPERS
|
ADJUSTABLE BOTTLE STOPPERS PROVIDED
|
|
SPILLAGE DUCT
|
SPILLAGE DUCT WITH TRAY PROVIDED TO COLLECT ANY SPILLAGE.
|
|
FILLING SPEED
|
UPTO 15 BOTTLES PER MINUTE, DEPENDING UPON NATURE
|
|
SYRINGES
|
MACHINE IS NOT PRIVIDED WITH SYRINGES. SYRINGES FOR THE REQUIRED PACKSIZE CAN BE SUPPLIED TO MEET YOUR REQUIREMENT
|
|
FILLING ACCURACY
|
+ 1% UNIFORM LIQUID PROPERTIES
|
|
DRIVE
|
MOTOR
|
0.75 H.P.MOTOR WITH OPRIONAL VARIABLE SPEED DRIVE
|
|
GEAR BOX
|
SPECIALLY DESIGNED GEAR BOX WITH ONE PIECE INTGRAL SHAFT WITHOUT ANY JOINTS TO DRIVE THE ECCENTRIC BLOCKS.
|
|
ECCENTRIC BLICK
|
ONE PIECE s.s.304 ECCENTRIC BLOCK FOR VOLUME ADJUSTMENT WITH HEAVY CONSTRUCTION.
|
|
PHYSICAL SPECIFICATIONS
|
MOC
|
ALL PARTS COMING IN DIRECT CONTACT OF THE PRODUCT MADE FROM S.S. 304. ALL OTHER PARTS MADE FROM MS/CI ( FOR GMP MODELS ALL PARTS ARE MADE FROM S.S.304 / COVERED WITH SS304 SHEETS)
|
|
GUARDS
|
BODY COVERING ,GUARDS ETC. ARE MADE FROM s.s.304
|
|
DIVING NOZZLE OPTION(IF-2D) FOR FOAMING LIQUIDS.
|
DIVING NOZZLE OPERATION
|
PNEUMATIC
|
|
NOZZLE HOLDER
|
ALUMINUM
|
|
PNEUMATICS
|
CAMOZZI MAKE
|
|
COMPRESSED AIR
|
TO BE ARRANGED BY YOU
|
|
STROKE
|
9 INCHES DIVING STROKE MAX.
|
|
CONTROL
|
WITH INDUCTIVE PROXIMITY SWITCH
|
|
OVERALL DIM
|
MAIN MACHINE
|
750 mm X 700 mm X 600 mm
|
|
SUPPORING FRAME
|
650 mm X 400 mm X 700 mm
|
|
NET WEIGHT
|
225 kgs APPROX WITHOUT SYRINGES
|
|
|
MOUNTING
|
MACHINE WITH FRAME PROVIDED WITH POLYAMIDE LEGS
|
