Volumetric Cup Filler

Volumetric Cup Filler
Volumetric Cup Filler
Product Code : DV 3TE
Product Description

Volumetric Cup Filler - Dust Free Model

We offer a complete range of Volumetric Cup Fillers in standard and customizable models. Semi-automatic Volumetric cup fillers are designed for filling free flowing powders and grannuals. GMP models are available to suit international quality standards specically for pharma and Food industry. These machines can be delivered with dust free enclosure to ensure that the healthy environment is maintained. This is specifcally requried where material is hazareodus to the health of the people working in the premises.

Simple construction and easy maintenace makes these machines highly suitable for industry where skilled man power is a major hurdle.Correction of volume can be done without stopping the machines to adjust the batch to batch various of the product.

Suitable for

- Chemical and Detergent Industry, Salt, Detergent, Grains,Pulses.

Salient Features

- Volumetric filler with dust free enclosure.
- Ideal for International Standard /Touch free environment
- Recommended for Hazardous materials
- Capacity to handle wide range of products and pack sizes.
- Correction of Volume can be done without stopping the machine.
- Easy changeover of product and pack sizes.
- Contact parts made from S.S.304( S.S.316 contact parts on request).
- Sturdy, simple construction assists maintenance and cleanliness.
-Jumbo models available for handling large volume of powders.

Technical Specifcations

Item Parameters Specifications
Operational specifcations Capacity Free flow granular powder from 150 cc to 1500 cc
Filling cups Telescoping filling cups for one pack-size (1000gms free flow salt) will be provided with the machine
Volume control  Telescopic cups with adjustable volume for compensation of variation in bulk density
Volume cont. Mechanism With helical gearing fiber hand wheel and ss spindle
No. Of heads Two
Operation mode  Manual with two operators for two heads
Filling speed  40 discharges per minute ( 17 discharges per minute on each side)
Filling accuracy + 2% at constant powder level in the machine hopper and consistency of bulk density
Powder feeding  To be arranged by you.
Drive Motor  0.75 hp motor
Gear box  Special heli-worm reduction gear box enclosure for helical gears
Physical Specifications Machine hopper 50 litres. With adjustable inclined baffle
Dozer disc  10mm thick machined ground dozer discs.
Machine body With heavy cast iron frames and top plat made from ss304.guards made from ss304
Discharge hopper Discharge hopper with outlet diameter to suit the pouch mouth
Moc  All parts coming in direct contact of the product made from s.s. 304. All other parts made MS/CI powder coated / painted.
Mounting Suitable for table top mounting. Optional supporting frame available.
Overall dimensions Main machine 1100mm x 850mm x 1300mm
Supporting frame(optional) 650mm x 400mm x 900mm
Net weight  300kgs approx
